◎Cold and hot water pipes in residential buildings◎Pure water conveying pipe◎Hot water circulation and heating supply pipe◎Tap water pipe◎Aquaculture pipe◎Water treatment pipe◎Food, beverage, drug factory water conveying pipe◎Industrial cold and hot water conveying pipes◎Central air conditioner condensate water conveying pipe◎Compressed air pipe
Return| specifications | D1 | D | d | I | H | G | A/box |
|---|---|---|---|---|---|---|---|
| Φ20x(1/2)" | 35.5 | 27.5 | 14.2 | 16.5 | 42 | 1/2" | 60×8 |
| Φ25x(1/2)"3 | 38 | 34.5 | 19 | 18.5 | 44 | 1/2" | 60×8 |
| Φ25x(3/4)" | 44 | 34.5 | 24 | 18.5 | 45 | 3/4" | 40×8 |
| Φ32x(1/2)" | 41 | 43.5 | 24 | 21 | 50 | 1/2" | 40×8 |
| Φ32x(3/4)" | 46 | 43.5 | 31 | 21 | 49 | 3/4" | 40×8 |
| Φ32x1" | 58 | 43.5 | 31 | 21 | 60.2 | 1" | 15×8 |
| Φ40x1(1/4)" | 72 | 52 | 39 | 22 | 65.5 | 1(1/4) | 10×8 |
| Φ50x1(1/2)" | 81 | 64 | 50 | 25.5 | 70 | 1(1/2) | 8×8 |
| Φ63x2" | 97 | 80 | 62.5 | 29.5 | 79.5 | 2" | 6×8 |
| Φ75x(5/2)" | 108.5 | 95.5 | 73 | 33.5 | 79.5 | 5/2" | 4×8 |
| Φ90x3" | 129.5 | 115 | 88 | 38.5 | 85.5 | 3" | 4×8 |
| Φ110x4" | 156.5 | 141 | 108 | 44 | 112.5 | 4" | 2×8 |
